High-performance electric fence energiser for 12 V operation
very high power reserves
with battery deep-discharge and overcharge protection. With LED earth-quality check
With device and battery monitoring
with digital fence voltage display
particularly low-impedance
for wildlife deterrence on long fences
outstanding fence security
Technical data: magnus A 10000 DC
Operating voltage: 12 V
Open-circuit voltage: approx. 9,500 V
Voltage on animal contact: approx. 7,200 V
Voltage at 500 ohm (short circuit): approx. 3,600 V
Pulse energy: approx. 4.5 J
Power consumption: 30–450 mA
Max. fence length (CEE): approx. 120 km
Recommended fence length (depending on vegetation): up to 50 km
Application recommendation:
Our newly developed high-performance electric fence energiser
magnus A10000 DC is the right choice for the
most demanding applications in the field of
12 V battery technology.
The unit is particularly low-impedance
and therefore ideally suited for maximum fence lengths.
It is highly effective even with heavy vegetation and, despite the
high output energy, economical in battery consumption. It
features microprocessor control, an
integrated deep-discharge protection, a digital
fence voltage display
and an earth control indicator
that allows the quality of the earthing to be monitored.
More sensitive animals can be contained by using
the second fence output with reduced power.
