Latest-generation AED device –
the semi-automatic external defibrillator
iPAD CU-SP1
EASY TO UNDERSTAND
Automatic volume
Immediately after switch-on, the device detects ambient noise and automatically adjusts the volume of its voice prompts accordingly. Especially in crowded railway stations, at airports or in factory halls with lots of loud background noise, this feature can be life-saving.
READY FOR IMMEDIATE USE
Pre-connected electrodes – cleverly stored
Already connected and well protected, the defibrillation electrodes are located on the underside of the device in an integrated storage compartment. This makes your AED even safer and faster to deploy! Are the electrodes new? If used or expired “intelligent” electrodes are connected, the smart defibrillator immediately tells you what to do.
SIMPLE CONTROL
Adult and paediatric mode
Is the patient a child? Thanks to a simple slider, you can quickly switch from adult to paediatric mode. The device then operates with less energy to protect the smaller heart muscle. Special paediatric electrodes are available as an option.
DOUBLE PROTECTION
Artifact and CPR detection
As an intelligent first-aid defibrillator, the CU-SP1 detects whether the patient is being touched by other people. In this case, it will not deliver a shock. Not only is the emergency patient optimally cared for – you as a first aider are protected too! In addition, the iPAD CU-SP1 detects whether you are performing chest compressions to ensure the best possible chances of survival for the emergency patient.
ALWAYS IN VIEW
The clear status display
Whether battery charge level or electrode status – the LCD display lets you keep the functionality of your iPAD in view at all times! Is your device ready for use? Regular self-tests check whether everything is OK. Do the defibrillation electrodes need to be replaced? The display warns you in good time, starting as early as three months before the expiry date.
AFTER USE
Memory and data transfer
The iPAD CU-SP1 stores up to five emergency deployments on an SD card. Would you like to evaluate the ECGs on your computer? Simply transfer the data via SD card or via infrared interface. With the optionally available CU-EX1 software, you can edit and archive the patient data.
Product data:
Defibrillator
Type: Semi-automatic external defibrillator
Model: CU-SP1
Manufacturer: CU Medical Systems, Inc.
Waveform: Biphasic truncated exponential pulse, E-cube technology
Delivered energy: 150 joules for adults, 50 joules for children, impedance-compensated
Charge time: Under 8 seconds
Controls
LCD display (electrode and battery status, proper functionality), metronome for chest compressions, voice prompts (automatic volume adjustment to the operating environment) and backlit pictograms, pre-connected electrodes, slider for adult and paediatric mode, information button for detailed voice instructions (optionally activatable),
shock button, on/off switch
Resuscitation guidelines
Standard default setting: 5 cycles with 30 chest compressions and 2 ventilations (in accordance with the CPR Guidelines 2010)
Custom settings
Number of chest compressions, number of ventilations, number of cycles, number of chest compressions per minute, pause duration, activation of the detailed instructions (individually adjustable in line with future guideline changes)
Self-tests
Automatic self-diagnostic test after switch-on and continuous functional tests during use; daily, weekly and monthly self-diagnostic tests
Manual self-diagnostic test after each battery insertion
Environmental conditions
Operation and storage: Temperature 0 °C to 43 °C, humidity: 5% to 95% (non-condensing)
Transport: Temperature -20 °C to 60 °C
Vibration protection: Switched on: complies with MIL-STD-810G, Fig. 514.6E-1, random test; Stand-by: complies with MIL-STD-810G, Fig. 514.6E-2, swept sine (helicopter)
Protection rating: Protected against dust and water jets, rating IP55 in accordance with DIN EN 60529: IP55
Drop protection: Withstands drops from up to 1.2 metres onto edges, corners or smooth surfaces
ESD: Complies with EN 61000-4-2:2001
EMC emissions: Meets EN 60601-1-2 limit values, method EN 55011:2007 + A2:2007, Group 1, Class B
EMC immunity: Meets EN 60601-1-2 limit values,
method EN 61000-4-3:2006 + A1:2008 Level 3 (10 V/m, 80 MHz to 2500 MHz)
Event documentation
Internal memory: Recording of up to 5 events, up to 3 hours of data
Data transfer: Via SD card or infrared interface
Data evaluation: PC software CU-EX1 (available as an option)
Power supply
Long-life battery 12 V DC; 4.2 Ah LiMnO2, at least 200 shocks or 8 hours operating time, at least 5 years stand-by time
Size and weight
Dimensions 260 mm x 256 mm x 69.5 mm
(width x length x height)
Weight 2.4 kg (including battery and electrodes)
