Mobile patient shower and transport trolley, for transferring a resident/patient in a lying position from the nursing bed to the care area and back.
The TR 3000 electric shower trolley offers, thanks to its unique design, a number of features that make operation and handling with the resident/patient easier. To cover as wide a care area as possible, the shower trolley is available in 3 different lengths.
- 1600 mm – for children in need of care
- 1900 mm – standard size range
- 2100 mm – extra-long for tall persons
SAFETY CHASSIS with two front twin swivel castors Ø 75 mm and two rear smooth-running swivel castors Ø 100 mm, each with a brake. Includes support for straight-line tracking via an additional locking option on the front castors. The complete drive concept is integrated into the chassis under a plastic cover.
TILT ADJUSTMENT consisting of two locking levers fitted at both ends of the shower trolley, enabling operation at any time. The lying surface can be adjusted in tilt by approx. 5 degrees in both directions.
LIFT MAST made of rust-free stainless steel. The asymmetrical position of the lift mast enables easier positioning of the resident/patient, as the lateral arrangement allows the bed to be approached/straddled more easily.
SHOWER PLATFORM, fully enclosed all around and padded for a comfortable lying position for the resident/patient. Both side sections can be folded down to facilitate positioning of the resident/patient, with the side rail on the resident side lying horizontally on the bed. This ensures easy transfer. Thanks to its special coating, the surface of the platform is non-porous and therefore easy to clean and disinfect. The shower platform has 2 drain openings, each with a drain plug and thread for attaching the drain hose. The shower trolley is also equipped with a neck cushion and a drain hose.
