(without battery)
low-priced and powerful
economical
for 9V and 12V operation
reliable
insensitive to vegetation
with fence monitoring
with earth stake and mounting post
Technical data Bison U 4000
Operating voltage: 9 V strong 9V extra strong
No-load voltage: approx. 7200 V approx. 9100V
Voltage at animal contact: approx. 4600 V approx. 5700V
Voltage at 500 ohms (short circuit): approx. 1800 V approx. 2200V
Pulse energy: approx. 0.25J approx. 0.4J
Power consumption: approx. 14-28mA approx. 19-48mA
Max. fence length (CEE): approx. 6km approx. 12km
Recommended fence length (depending on vegetation): up to 2-4km approx. 5-8km
Operating voltage: 12V/230V strong 12V/230V extra strong
No-load voltage: approx. 7800 V approx. 9800 V
Voltage at animal contact: approx. 5100 V approx. 6400 V
Voltage at 500 ohms (short circuit): approx. 2300 V approx. 2900 V
Pulse energy: approx. 0.85J approx. 1.30J
Power consumption: approx. 28-75mA approx. 35-110mA
Max. fence length (CEE): approx. 25km approx. 25km
Recommended fence length (depending on vegetation): approx. 6-15km approx.
8-18km
Application recommendation:
Our classic, the BISON U4000, is a unit for all applications where either low or medium output is required. It is just as suitable for use on larger paddocks and for wildlife deterrence, as well as for operation on sheep nets, as it is for the farm and garden. Low power consumption, switchable output levels and the option of 9V or 12V operation make it the first choice when it comes to flexibility and cost-effectiveness. Thanks to the integrated deep-discharge protection, your 12V battery is now also optimally protected.
