The highlights of the Grande F at a glance:
- Good value for money
- Affordable and environmentally friendly heating with wood
- Large viewing window
- Baking compartment with integrated oven thermometer
- Flat hob top with removable ring
- Rear flue pipe connection
- Cooking and baking without electricity or gas
- Timeless design
- Solid, robust metal construction
- Elegant ceramic cladding
- Cast grey body, heat-resistant painted finish
- Compliant with BImSchV Stage II (no filter or other retrofits required)
- Large firebox / suitable for large logs (up to 45 cm)
- Large door for easy loading of fuel
- Reliable, smooth-running door closing mechanism
- Elaborately sealed construction
- Easy operation
- High heat output with good efficiency
- Airwash system (keeps the viewing window clean for a long time)
- Low flue gas temperature
- Log storage compartment
- Removable ash pan
- No additional fine dust filter required
- High-quality workmanship
- High output
- Suitable for continuous burning
Technical data:
Nominal heat output: kW 12
Efficiency: % 76.91
CO emissions at 13% O2: % 0.0988
Particulate emissions at 13% O2: mg/Nm3 26.40
NOx at 13% O2: mg/Nm3 100.04
OGC at 13% O2: mg/Nm3 67.55
Flue gas value triple: g/s-°C-Pa 9.93-230-12.8
Fuel consumption: kg/h 3.68
Appliance dimensions
Width: mm 614
Depth: mm 597
Height: mm 1040
Oven dimensions
Width: mm 394
Depth: mm 395
Height: mm 256
Combustion chamber dimensions
Width: mm 432
Depth: mm 350
Height: mm 365
Flue pipe connection: mm 150 only possible at the rear (top edge from floor at approx. 93 cm)
Colour: cast grey
Cladding: ceramic
Weight: kg 182
Weight with packaging: kg 202
Packaging dimensions
Width: mm 730
Depth: mm 730
Height: mm 1200
Safety distance to combustible components*:
Minimum distance, in mm
Side=400
Rear=400
Front=1000
* These distances only need to be observed in a combustible situation, e.g. if installed in front of a wooden wall!
